SmartScope® Quest™ 800 (790 x 815 x 250mm) – An extremely accurate floor-model coordinate measurement system incorporating touch probe, micro-probes and the patented TeleStar® telecentric TTL laser for versatility and accuracy. The Quest 800, with its extensive XYZ measurement volume (and available 300 mm Z axis), is designed to measure very large parts. The system supports touch trigger and scanning probes, patented TeleStar® telecentric TTL laser or DRS™ off-axis laser and micro-probes for flexible measurement. Combined with Quest’s multisensor support, high-speed stages and the ability to switch between sensors at any point in a measurement routine, the dual-rotary option allows SmartScope Quest 650 to automatically measure complex forms like turbine blades, vanes and airfoils. XY acceleration of 0.25 g and 200 mm/sec Z-axis speed contribute to high throughput.
High-speed linear motors in the X and Y axes move at a rapid 300 mm/sec. It also provides high accuracy movement of large parts. Its massive granite base and thermally stable Meehanite® bridge support high-performance linear motor drives. SmartScope Quest 650 provides high throughput and high accuracy simultaneously.
SmartScope® Quest™ 650 – The largest high-accuracy system from OGP®. The bridge design limits measured part motion to the Y axis. This yields high-speed stage translation without vibration, maximizing measurement throughput. A solid granite bridge design platform rests on a sturdy, steel support structure. SmartScope® Quest™ 450 – An extremely accurate floor-stand coordinate measurement system designed to incorporate optical, touch probe, micro-probes and the patented TeleStar® telecentric TTL laser for versatility and accuracy. Both the 450 and 450 with extendable Y are designed to measure larger parts or to accommodate fixtures of multiple parts or rotary indexers. #Smartscope vantage 650 software#
It also comes standard with MeasureMind® 3-D MultiSensor metrology software that accepts data points from all sensors and builds a model in 3-D space. It offers a unique “elevating bridge” design that yields large XYZ travel with compact machine size. Axial straightness and perpendicularity are built in to meet stringent volumetric specifications and patented telecentric TeleStar 10:1 metrology zoom lens utilizes interferometric technology to provide excellent optical performance over its entire range. Add optional TeleStar® telecentric interferometric through-the-lens (TTL) laser, touch probe or micro-probe to configure a highly capable multisensor system. With an expansive XYZ measurement volume to accommodate large parts, it combines state-of-the-art video and autofocus to deliver high productivity.
SmartScope® Quest™ 300 (300 x 300 x 250mm (12x12x10″) – Offers the measurement versatility and accuracy needed for the most critical and demanding parts. Software options for SmartScope Quest include seamlessly integrated programs for CAD import, contour analysis and fitting and customized report generation and data export. Additionally, most sensors used on SmartScope Quests are deployable and retractable under program control for unattended operation. MeasureMind® 3-D MultiSensor calibrates sensor data to a common reference frame so any sensor can be used in a measurement routine at any time. The patented TeleStar® 10:1 zoom lens is completely telecentric and automatically calibrated throughout its range for distortion free, high-fidelity images – perfect for high-accuracy metrological applications.Īll Quest systems support tactile, laser and micro-sensors for the most complete high-accuracy measurements possible in a single part setup. Accurate video measurements require accurate images and Quest offers the best optical performance available. #Smartscope vantage 650 full#
The SmartScope® Quest™ is a high-accuracy metrology system designed to use a variety of sensors for full 3-D measurement.
